The new TB55 battery uses higher performance and a higher density battery cell with an overall larger capacity. Its performance in low temperature environments has been optimized with a built-in self-heating system. This self-heating function can be enabled either automatically or manually. The management unit constantly monitors battery status, making all information, including battery level and battery temperature, easily visible in DJI GO.
Flight Times Based on Camera:
- X5S (33 minutes)
- Z30 (32 minutes)
- Z30+XT (28 minutes)
- Z30+X5S (26 minutes)
Specifications:
Capacity: 7660 mAh
Voltage: 22.8 V
Battery Type: LiPo 6S
Energy: 176.93 Wh
Net Weight: 885 g
Charging Temperature: 41° to 104° F (5° to 40° C)
Operating Temperature: -4° to 113° F (-20° to 45° C)
Max Charging Power: 180 W
*Battery duration is recorded in an ideal flight situation, subject to real flying environments and conditions.
